Description
Enhanced Accuracy
The PX940 series delivers industrial printing with ±0.2 mm (0.0079 in) precision, virtually eliminating unreadable labels and enhancing production efficiency while lowering operational costs.
Integrated Label Verification
Advanced label verification technology ensures every barcode’s accuracy, providing instant pass/fail status and ANSI grading for immediate corrective actions and compliance with regulatory standards.
User-Friendly Design
Featuring a color touchscreen interface and quick side-loading design, the PX940 is easy to use and maintain. Smart printing capabilities enable direct configuration and printing without a host computer.
Operational Intelligence
With Operational Intelligence software, the PX940 offers predictive analytics and real-time data on printer health, allowing managers to monitor their fleet and proactively resolve issues, maximizing uptime.
Perfect for Regulated Environments
Ideal for transportation, logistics, pharmaceuticals, healthcare, and automotive sectors, the PX940 meets high-precision printing demands. Available with or without an integrated verifier, both versions support Bluetooth® connectivity.
Robust and Efficient
The all-metal print mechanism, combined with easy printhead and tool-free platen roller replacements, minimizes downtime. Supporting various media types and achieving speeds of up to 350 mm/s (14 ips), the PX940 ensures maximum efficiency.
Features
Features
- Edge Intelligence Providing Customers with Predictive Analytics
- Integrated Label Verification Technology Providing Error-free Printing
- Precision Printing with Registration of +/-0.2 mm
2D Barcodes
- All major 2D barcodes
Verifier Scan Resolution
- 600 dpi
Applications & Compatibility
Compatible Software
- BarTender
- Nicelabel
- Operational Intelligence
- SOTI Connect
- Teklynx Labelview
Application
- Automotive
- DC/Warehouse
- Healthcare
- Manufacturing
Technical Specifications
Compatible Drivers
- CUPS Driver for Linux
- Certified Device Types for SAP
- InterDriver Windows
Resolutions
- 203 dpi
- 300 dpi
- 600 dpi
Print Speeds
- 50-350mm/s (2-14 ips)
Print Method
- Direct Thermal
- Thermal Transfer
Linear Barcodes
- All major 1D barcodes
Downloadable Font Type
- Bitmap Font
- OpenType Font (TrueType based)
- TrueType Font
Printer Media Type
- Label
- RFID
- Ribbon
- Tag
Wireless Communication
- Bluetooth LE
- NFC
Printer Command Language
- C# Smart Printing
- DPL
- Fingerprint (FP)
- Intermec Printer Language (IPL)
- WMSDirect Protocol (DP)
- XML-enabled for SAP AII and Oracle WMS
- ZSim2 (ZPL-II)
RAM Memory
- 1 GB
Memory
- External Multi-GB USB memory device (FAT16/FAT32)
Image File Format
- BMP
- GIF
- PCX
- PNG
Flash Memory
- 256 MB
Printer Connection Interface
- Applicator Interface
- Industrial interface
- Parallel Interface (IEEE 1284)
- RS-232
- USB 2.0 Host x2
Operating Frequency
- 50 - 60 Hz
Verifier Scan Width
- 108mm (4.25 in)
Verifier Light Source Wavelength
- 660 nm
Verified Linear Barcodes
- Code 128
- Code 39
- EAN-128
- EAN-13
- EAN-8
- GS1 Databar Expanded
- GS1-128
- HIBC 128
- HIBC 39
- ISBT 128
- ITF-14
- Interleaved 2 of 5
- RSS14E
- SCC-14
- UPC-A
- UPC-E
Verified 2D Barcodes
- Data Matrix
- ISBT Data Matrix
- QR code
Verification Standard
- ISO 15415/15416
Platform
- Honeywell Printer Edge
Dimensions & Weight
Overall Dimensions
- 50.6 x 39.87 x 26.1 cm (19.92 in x 15.70 in x 10.28 in)
Maximum Ribbon Length
- 450 m (1476 ft)
Weight
- PX940 with Verifier: 23.5 kg (51.81 lbs)
- PX940: 23 kg (50.71 lbs)
Maximum Media Roll Diameter
- 213 mm (8.38 in)
Electrical Specifications
Operating Voltage
- 100 - 240 V AC
Operating Characteristics
Operating Temperature
- +5°C to +40°C (+41°F to +104°F)
Storage Humidity
- 20 - 85 % non-condensing
Operating Humidity
- 20 - 85 % non-condensing
Storage Temperature
- -20°C to +70°C (-4°F to +152°F)
Overview
Warranty Duration
- One year factory warranty
Brand
- Honeywell
Others
Print Width
- 4 inch
Print Volume
- Up to 10,000
Print Technology
- Thermal Transfer
Print Resolution
- 203 dpi
- 300 dpi
- 600 dpi
Industry
- Healthcare
- Logistics & Warehouses
- Manufacturing
Connectivity
- Ethernet
- Wi-Fi
